MPrint
The additive manufacturing process offers the user a wide range of applications, and value-added use cases can be generated almost anywhere.
Our systems are in operation in various industries as well as with different materials – and applicable for many more as well.
The 200W fiber laser allows great productivity and precision.
The cartridge system enables both safe and clean powder handling while minimizing direct powder contact for the user.
With a build volume of 150mm x 150mm x 150mm, the MPRINT has the largest construction area in its performance range and is therefore very flexible.
With a focus diameter of 70µm and Galvo scanner, a wide field of applications opens to the user.
MPUREpro
One machine, two functions: with the MPUREpro, the unpacking of a component and the sieving of processed powder are combined in one machine. This means time and cost savings for the user.
The integrated ultrasonic sieve recycles processed powder. For this, a full overflow cartridge and an empty supply cartridge are inserted into the holders. The sieving then runs autonomously and independently of the user.
Unpacking a component with the MPUREpro is safe and easy for the user. Thanks to the chamber door as well as the gloves, the component is unpacked in a closed chamber. The integrated connection for an ATEX vacuum cleaner further simplifies unpacking.
Complete Product Solution
Using MONE, you can quickly and conveniently load your component onto the machine – you don’t have to go to the machine itself to do this but can do it wherever you are.
After you have prepared the MPRINT for printing, you can start the build job.
Once the part is printed and the build module is inserted into the MPUREpro with the lifter, you can unpack it without direct powder contact and sieve processed powder at the same time.
Machine Operation
The machine operation of MPRINT is easy to use and allows you to start a build job in just six steps.
- Select build job
- Prepare build module
- Check powder supply
- Check overflow powder
- Check machine
- Apply first layer
The machine operation guides you step by step through the individual phases of print preparation. In this way, you don’t forget a single step, you avoid mistakes, and you achieve fast results. The machine supports you from start to finish.
Powder and Cartridge System
The problem of unsafe and unclean powder management is solved with the BOLDSERIES by the cartridge system.
- Separation of supply and overflow cartridges avoid risk of mix-ups.
- Direct powder contact for the user is significantly reduced.
- Most of the processed powder can be reused.
The machine operation guides you step by step through the individual phases of print preparation. In this way, you don’t forget a single step, you avoid mistakes, and you achieve fast results. The machine supports you from start to finish.
