Multifunctional Metrology Laser 3D Scanner
- Blue laser & Infrared light
- Accuracy of 0.02mm
- Powerful and ergonomic
- Reddot winner 2024
Technical Data
- High-speed Scanning50 or 26 laser lines
- Detailed Scan7 laser lines
- Deep Pockets1 single line
- No Markers ScanInfrared mode
- Accuracy0.02 mm
- Max. FOV520 × 510 mm / 600 × 600 mm
- Volumetric Accuracy0.02 + 0.033 mm/m
- Point Distance0.05 ~ 10 mm / 0.1 ~ 3 mm
- Scan SpeedUp to 3,600,000 points/s
- Weight620g
- CertificationsCE, FCC, ROHS, WEEE, KC, FDA, UKCA, IP50, TISAX
- Accuracy CertificationVDl/VDE 2634 Part 3 (ISO 17025 certificated lab)
